Uhmwp Chemical Hose
Sizes: 3/4″, 1″, 1-1/4″, 1-1/2″, 2″, 2-1/2″, 3″, 3-1/2″, 4″
Application: Softwall hose designed with ultra-high molecular weight polyethylene tube, excellent in handing a wide range of chemicals, petroleum products and oils.
Temperature range: -40℃(-40℉)to +120℃(+248℉）
Tube: White, smooth, Ultra High Molecular Weight Polyethylene (UHMWPE)
Reinforcement: High strength synthetic cord and helix wire. Anti-Static cooper Wire upon request
Cover: Green/Blue, smooth(wrapped finish), EPDM rubber, resistant to chemical, weathering and ozone
Features:
- Abrasion and Ozone Resistant: The cover protects the body from stiffening and cracking caused by ozone and UV exposure. It also added abrasion resistance for extended hose life
- Non-Kinking: The internal helical wire structure helps prevent kinking.
- Multi-Ply Acid Discharge Hose: Designed to handle most of common acids and alkali solutions under pressure.
- Multi-Ply Acid Suction Hose: This hose features a high-tensile textile cord with wire helix to prevent collapse under vacuum conditions.
A rubber medium duty chemical suction and discharge hose designed to meet the general needs of the industry
The hose is equipped with a steel spiral to ensure that it can withstand the toughest conditions. Fabric reinforcement further increases its strength and durability. Its superior design means that it works comfortably in the face of external pressure and can handle suction and discharge operations with ease.
The hose is ozone-resistant, making it an excellent choice for outdoor applications exposed to UV rays and other environmental factors.
Outstanding durability, chemical resistance and safety features
Can handle a wide range of acids, alkalis and other chemical deliveries
Maximum pressure rating of 150 psi and a 3:1 burst ratio (safety factor) make it a reliable and safe choice you can trust
|
Item code |
I.D. (inch) |
I.D. (mm) |
O.D. (mm) |
Work Pressure (bar) |
Work Pressure (psi) |
Burst Pressure (bar) |
Burst Pressure (psi) |
Max. Length (m) |
Max. Length (ft) |
|
9002001 |
3/4" |
19.1 |
31 |
10 |
150 |
40 |
600 |
60 |
200 |
|
9002002 |
1" |
25.4 |
37 |
10 |
150 |
40 |
600 |
60 |
200 |
|
9002003 |
1-1/4" |
31.8 |
44 |
10 |
150 |
40 |
600 |
60 |
200 |
|
9002004 |
1-1/2" |
38.1 |
51 |
10 |
150 |
40 |
600 |
60 |
200 |
|
9002005 |
2" |
50.8 |
67 |
10 |
150 |
40 |
600 |
60 |
200 |
|
9002006 |
2-1/2" |
63.5 |
79 |
10 |
150 |
40 |
600 |
60 |
200 |
|
9002007 |
3" |
76.2 |
92 |
10 |
150 |
40 |
600 |
60 |
200 |
|
9002008 |
3-1/2" |
88.9 |
105 |
10 |
150 |
40 |
600 |
60 |
200 |
|
9002009 |
4" |
101.6 |
118 |
10 |
150 |
40 |
600 |
60 |
200 |
What are UHMWPE Chemical Hoses and their Structure?
A transparent, food-grade UHMWPE liner is used to create UHMWPE Chemical Hose. High-tensile synthetic fabric, steel wire helix, and anti-static copper wire are used as reinforcement. It has several key features, including suction and discharge of all corrosive compounds, particularly strong aromatic solvents, and resistance to weather, ozone, and abrasion.
A rubber chemical suction and discharge hose are lightweight, flexible, and effective at handling various chemicals, petroleum products, and oils. It has unique multi-ply design makes it crush and kink-resistant, making it ideal for use in demanding abusive transfer applications. Almost every common industrial chemical used today may be transferred using the hose.
