Automotive Brake Hose

Name: Automotive Brake Hose
Tube: EPDM
Reinforcement: High strength synthetic fiber;
Middle layer: Using viscosity strengthen middle rubber between reinforcement to provide h-igh dynamic capability
Cover: EPDM, perfect heat and ozone resistance.

Send Inquiry

Product Introduction

Application: In addition to the pipe joints in the brake system, it is used to transmit or store the air pressure flexible delivery conduit for automobile brake booster, and is used for large and medium-sized trucks, large and medium-sized buses, heavy trucks, and large coaches in compressed air brake systems;
Inner layer: black synthetic rubber (NBR);
Braided layer: high-strength fiber braiding;
Outer layer: black synthetic rubber (CSM);
Applicable temperature: -40℃~+100℃;
Surface texture: cloth texture, stripes or smooth surface;
Product characteristics: The hose is woven with multiple strands of high-strength fibers, with good flexibility, burst resistance, and high tensile strength. After the tube body is compressed, the elongation is small. It has good weather resistance, ozone resistance, high and low temperature resistance, and stable braking effect;
Applicable standards: SAE J1402, GB16897;
Packaging: double-layer woven bag/carton packaging/pallet;

Number	Size	Inside diameter	Outer diameter	Wall thickness	Working pressure		Burst pressure
Number	(inch)	(mm)	(mm)	(mm)	(Mpa)	(KG)	(Mpa)	(KG)
1	3/16	5±0.2	12±0.3	3.5	2	20	>8	>80
2	1/4	6±0.2	13±0.4	3.5	2	20	>8	>80
3	5/16	8±0.3	15±0.4	3.5	2	20	>8	>80
4	3/8	9.5±0.3	17±0.4	3.75	2	20	>8	>80
5		12±0.3	20±0.4	4	2	20	>8	>80
6	1/2	13±0.3	22±0.4	4.5	2	20	>8	>80
7		14±0.3	23±0.4	4.5	2	20	>8	>80
8	5/8	16±0.3	25±0.4	4.5	2	20	>8	>80
